Application Example of Installing a Thin Magnetic Clamp on a Sodick Injection Molding Machine

Application Example of Installing a Thin Magnetic Clamp on a Sodick Injection Molding Machine.
In Association with Sodick IMM by Plustech Inc.

For Injection Molding Machines
Model：MAK/MAG

Application Example of Installing a Magnetic Clamp on a 1800t Injection Molding Machine

Machine Capacity：1800ton class、Magnetic Plate：MAK1800 (Plate Thickness 50mm, The Number of Discharges : 8, Applicable Temperature 100℃, Detection System : MIMS)

For Injection Molding Machines
Model：MAK/MAG

Setup Operation with Linear Conveyor: High-Speed Setup・Reduce Cycle Time

By using mechanically operated smart series location clamp (model KSL), it is able to mount and remove a pallet on a slider with the linear conveyor’s driving force.
Time efficient. Reduce the cycle time.
In association with: Yamaha Motor Co., Ltd.

FA・Industrial Robot Related Products
Model：KSL

Example of chuck plate replacement time comparison! Only 6 seconds! No tools required!

Chuck Plate Change Over Time Comparison
Standard Mounting vs Quick Chuck Changer
Removal Time: Only 3 seconds with quick chuck changer!
Mounting Time: Only 3 seconds with quick chuck changer!

For Injection Molding Machines
Model：SXQ0030(Payload：5kg)

No Power Source Required. High-Speed Pallet Change and Workpiece Clamping

Smart Series – Powered by Any Power Source, Smart Fit on Any Application.
This video shows application examples of Kosmek’s Smart Series Pallet Clamp and Swing Clamp.
Pallet Clamp : Enables easy setup of pallets.
Swing Clamp : The lever descends as it swings to clamp a workpiece.

FA・Industrial Robot Related Products
Model：KSS/KSL

Work Support with new function! Model WNC

When a work support cannot operate with plunger spring force due to adherence such as dry sludge after a long-time machine stop, Knockout Function releases the adherence and secure the proper operation.

Machine Tool Related Products
Model：WNC

Mechanical Robotic Hand Changer, Model SMR

No power source required.
Zero-backlash, High accuracy and High rigidity.
Mechanical Robotic Hand Changer, model SMR.

FA・Industrial Robot Related Products
Model：SMR

Robotic Hand Changer with 300kg Payload

Changing two types of hands by a robotic hand changer with 300kg payload.
In Association with HCI CO., Ltd.

FA・Industrial Robot Related Products
Model：SWL

Payload 15 kg! Quick Change of Chuck Plate

Quick Chuck Changer specially designed for injection molding picker robot.
15 kg payload model has been newly added to the line-up!

For Injection Molding Machines
Model：SXQ

Robot Cart Connection!! Automatic Workpiece Loading into Machining Equipment

Connect the robot and the machining equipment.
Allows for the floor height variation by connecting the floatable pallet carrying the robot to the equipment, not connecting the entire cart to the equipment.

FA・Industrial Robot Related Products
Model：WVG

New model “High-Power Pneumatic Frog Clamp”

What is “Frog Clamp”? What is “High-Power Pneumatic”?
Find the details on this video!
It also shows the difference between “Frog Clamp” and “Link Clamp”.

Machine Tool Related Products
Model：WFE

Quick change of collaborative robot DOBOT CR’s hand

Application example of Manual Robotic Hand Changer with DOBOT CR Series.

FA・Industrial Robot Related Products
Model：SXR

Mount it on a wall surface! Pneumatic Swing Clamp with powerful swing mechanism – model WHC

Pneumatic swing clamp：model WHC can be used in vertical position (mounted on a vertical surface). *If the lever is too heavy, it may not work properly or may cause malfunction. For the calculation of the weight and center of gravity of the lever that can be used in vertical position, please refer to the cautions in the catalog.

Machine Tool Ralated Products / FA・Industrial Robot Related Products
Model：WHC

Air Non-Leak Coupler Application Example : Air chuck + Roundness measuring machine

KOSMEK’s Air Non-Leak Coupler can hold air pressure by disconnecting the air circuit under pressure.
In Association with NAKA SEIKI CO.,LTD.

Machine Tool Related Products
Model：BWA/BWB

Hand Change of Kawasaki duAro2 by Manual Single-Setup

Manual Robotic Hand Changer (Model SXR0030) can be directly mounted to KAWASAKI duAro1/duAro2 (dual-armed collaborative robot).
Robot : Kawasaki duAro2

FA・Industrial Robot Related Products
Model：SXR

Hydraulic Clamp | Mold Back-Plate Variance Possible up to 20mm

The demo video introducing the hydraulic clamp lever spacer model allowing for mold back-plate variance up to 20mm

for Injection Molding Machine/For Press Machines
Model：GBC-F

Manual Single-Setup of UR10e Collaborative Robot’s Hand

Manual Robotic Hand Changer (Model SXR0070) can be directly mounted to collaborative robots UR3, UR3e, UR5, UR5e, UR10 and UR10e manufactured by Universal Robots.
Robot : Universal Robots UR10e

FA・Industrial Robot Related Products
Model：SXR

Introducing Application Examples of FA Pneumatic Hole Clamp

Enables one robotic hand to transfer multiple workpieces.

FA・Industrial Robot Related Products
Model：WKH

One of the World’s Smallest Pneumatic Swing Clamp

Powerful swing mechanism with 3 steel ball tracking.
High-speed and high-accuracy pneumatic swing clamp (rotary clamping cylinder) with long operational life.

FA・Industrial Robot Related Products
Model：WHC

Quick Chuck Changer for Injection Molding Picker Robot

Quick Chuck Changer for Injection Molding Picker Robot

for Injection Molding Machine
Model：SXQ

High-Accuracy Bore Locating Cylinder with Large Expansion Stroke

Bore Locating Cylinder holds and locates a workpiece by expanding its pin diameter.

Machine Tool Related Products
Model：VFP

Side Clamp : Specialized for Side Push

Suitable for side push, Side Clamp is a solution for tooling clearance issue.

Machine Tool Related Products
Model：LSA / LSE

Single-Acting Clamp with Action Confirmation

Only one air port to confirm clamp and unclamp actions.
7MPa single-acting swing clamp and link clamp with action confirmation are newly added to the lineup!

Machine Tool Related Products
Model：LGV / LJV

[Special Demo] Fully Automated Side Load Mold Change System Example

Our proposal for fully automated mold change system.
Robot：OMRON TM12

for Injection Molding Machine

Setup Change Example by Moving a Robot with a Cart

Setup Change Example by Moving a Robot with a Cart
Robot setup changeover example:
High-accuracy locating and connecting of the fixture on the manual cart.
Robotic tool change is easy and quick with the manual tool changer.

In Association with DENSO WAVE INCORPORATED
Robot：DENSO WAVE COBOTTA

FA・Industrial Robot Related Products
Model：SWT / RQC / SXR / WNC /VRA /WPH

Quick Manual Change of Chuck Plate for YUSHIN Take-out Robot

Manual Robotic Tool Changer enables quick change of a chuck plate.
Application example with take-out robots manufactured by YUSHIN PRECISION EQUIPMENT.
Take-out robots in this video：FRA / YcⅡ-150

For Injection Molding Machines / FA・Industrial Robot Related
Model：SXR

Tool Changer Application Example – Robotic Machining Center INFINITY KATANA –

Robotic Hand Changer is installed to
Robotic Machining Center INFINITY KATANA
In Association with：INFINITY SOLUTIONS INC.
Robot：KUKA AGILUS KR10 R1100-2

FA・Industrial Robot Related Products
Model：SWR

Ball or Roller? Which to Choose?

Hydraulic Free Roller Lifter (Ball Model) model RQA
Hydraulic Lifting Die Lifter (Roller Model) model RA
Introducing features of each model.

For Press Machines
Model：RQA,RA

Quick Manual Change of Robotic Hand for Collaborative Robot FANUC CRX

Manual Robotic Hand Changer has been installed to
FANUC Collaborative Robot CRX-10iA.
In association with：DAIDO CO., LTD.
Robot：FANUC Robot CRX-10iA

FA・Industrial Robot Related Products
Model：SXR0070

Quick Manual Change of Chuck Plate for STAR SEIKI Take-out Robot

Manual Robotic Tool Changer enables quick change of a chuck plate.
Application example with a take-out robot manufactured by STAR SEIKI.

For Injection Molding Machines / FA・Industrial Robot Related Products
Model：SXR

Mold Locator Application Example

With Kosmek Mold Locator, a locating ring is not required.
Mold change becomes quick and easy.
In Association with：FUKUYAMA GOSEI CO., LTD.

for Injection Molding Machine
Model：MHB

Vertical Folding Pre-Roller Application Example

Pre-roller enables die loading with a crane and no interference with a machine slide.

For Press Machines
Model：MR

Manual Quick Change of MELFA ASSISTA Hand

Manual Robotic Hand Changer is used for MELFA ASSISTA collaborative robot.
In Association with：Mitsubishi Electric Corporation
Robot：MELFA ASSISTA (RV-5AS-D)

FA・Industrial Robot Related Products
Model：SXR

Pneumatic Free Roller Lifter(Die Lifter) Application Example

Pneumatic Free Roller Lifter enables to move the die 360° flexibly on the bolster.

For Press Machines
Model：RQC

High-Accuracy Location Clamp + Manual Cart + Robot

Solution that connects manual carts and AGVs with robots by “Mechanical Locking”.
In Association with Inaba Denki Sangyo Co., Ltd.

FA・Industrial Robot Related Products
Model：SWT,RQC,WNC,JWC/JWD,SWR,VRA

Magnetic Clamp | KOSMEK ORIGINAL DESIGN & PRODUCTION

KOSMEK Magnetic Clamp
Designed and Produced in Japan

for Injection Molding Machine
Model：MAK
